Amphenol CS-DSDHD44MF0-001.8M 44-Pin (HD44) Deluxe HD D-Sub Cable - Copper Shielded - Male / Female 1.8m (6-feet)

Product: CS-DSDHD44MF0-001.8M

Buy 1.8m (6-feet) Amphenol CS-DSDHD44MF0-001.8M Cables Direct from the Factory at Cables on Demand. 44-pin (HD44) Copper Shielded High Density Male/Female D-Sub Cables by Amphenol provide exceptional performance in commercial, industrial or enterprise applications where longevity and repeated disconnects are required. Our fully assembled Deluxe HD D-Sub Cable integrates copper tape + aluminum mylar shielded 24 AWG data-grade wire with pre-terminated HD44 (aka DB44HD) male and female d-sub connectors. Perfect for RS232 serial data, prototype, control and low-voltage applications using the 44-pin HD44 interface. Note: Other cable lengths from this same part number series, if available, will be also be displayed with their corresponding list prices. OEM-customized length, color and label options available by request.
Part Number Color Length Qty Available / Availability Qty Unit Price
CS-DSDHD44MF0-002.5 Gray 2.5ft 251 / In stock EA
1-50 $27.68 /EA
51+ $26.30 /EA
CS-DSDHD44MF0-005 Gray 5ft 577 / In stock EA
1-50 $35.32 /EA
51+ $33.55 /EA
CS-DSDHD44MF0-010 Gray 10ft 1107 / In stock EA
1-50 $41.54 /EA
51+ $39.46 /EA
CS-DSDHD44MF0-015 Gray 15ft 13 / In stock EA
1-50 $55.54 /EA
51+ $52.76 /EA
CS-DSDHD44MF0-025 Gray 25ft 2 / In stock EA
1-50 $84.42 /EA
51+ $80.20 /EA
CS-DSDHD44MF0-050 Gray 50ft 0 / Out of stock EA
1-50 $156.55 /EA
51+ $148.72 /EA
CS-DSDHD44MF0-001.8M Gray 1.8m (6ft) 163 / In stock EA
1-50 $38.99 /EA
51+ $37.04 /EA
  • Current Promotion -- Enjoy $100.00 OFF Online Orders Over $500.00 Automatically at Checkout Thru 5/16
  • 44-Pin (HD44) Deluxe High-Density D-Sub Cable Assembly by Amphenol
  • Connectors: HD44 male to HD44 female D-Sub connectors pre-installed
  • Cable: 24 AWG UL listed with copper tape + aluminum mylar shields
  • Straight-through wiring (i.e. pin 1 to pin 1) design per industry standards
  • Perfect for low-voltage signals & DCE/DTE RS232 serial communications
  • 100% EMI/RFI shielded design combines aluminum mylar and copper tape
  • Fully populated with Gold-plated contacts for superior signal continuity
  • Rugged UL94V-0 flame-resistant PVC jacket and overmold for strain relief
  • 300V voltage handling capacity at temperatures up to 80 degrees Celsius
  • Available in multiple cable lengths to meet your specific requirements
  • Cables can be easily cut in half and custom terminated for prototyping
  • RoHS compliant
